Analysis Type:

Clinical Chemistry, Turbidimetric, DOA, ISE

Throughput:

Up to 240 Chem. Tests/hr for double reagent
Up to 420 Chem. Tests/hr combined
Up to 180 ISE Tests/hr

Water Consumption:

3300ml/hr ±20%

ISE:

Na, K, Cl (indirect potentiometry)

Reagent:

80 Total (40 using 50 or 80 ml vessels + 40 using 10 or 20 ml vessels

Reagent bay temperature:

From 5-15 ˚C

Reaction Volume:

180-380 µL

Reading Cuvettes:

64 non-disposable, optical glass

Sampling Arms:

2: one for samples and one for reagents

Sample & Control/Calibrator Positions:

60

Test Modes:

Sequential access, Batch, STAT

Test Directory:

up to 500 + Relation test

Photometer:

340, 380, 405, 436, 480, 510, 546, 578, 600, 630, 650, 600, 740, 800 nm

Dimensions:

HxWxD; 47x84x60 cm

Weight:

60 Kg
