Product Specifications



Advantages

Result :

Quantitative

Accuracy :

≥±15%

Measuring Range :

R≥0.97

Precision :

CV≤10%

Stability :

σ≤±8%

Quality control :

Independent quality control mode with Curve

Technical Data

Screen :

7 inch color touch screen

Communication Interface :

Serial, Ethernet, USB, Mini USB, Micro SD card

Printing :

Built-in embedded thermal printer or connect with external printers

LIS Communication :

Two-way communication

Data Transfer :

Wireless transmission can be added soon

Reader :

ID Card

Result Output :

U Disk, LIS or Printer

Memory :

100000 tests

Test Mode :

Quick Test Mode and Standard Test Mode

Result time :

To get results in 10s under Quick Test Mode

Software :

PC Side

Dimension (L*W*H) :

268*240*115 mm

Weight :

3.2 kgs

Sample Material

Sample Type :

Serum / Plasma / Whole blood

Sample Volume :

≤ 200 ul

Operation Condition

Temperature Range :

10 to 30 °C

Relative Humidity :

10-80% (no condensation)

Maximum Altitude :

3,000 m

Storage Condition

Temperature Range :

-10 to 60 °C

Relative Humidity :

≤70 %
